Weight
|
16.9 Kg |
|
type
|
Digital Mixer |
|
Number of channels
|
64 |
|
Number of microphone inputs
|
32 |
|
Phantom power support
|
yes |
|
Physical outputs
|
22 |
|
Feader type
|
Motorized feader |
|
Number of Feader
|
33 numbers |
|
sound effect
|
yes |
|
Equalizer specifications
|
Parametric |
|
Equalizer bands
|
4 |
|
Computer connection
|
USB & Network |
|
Max.number of input channels
|
64 |
|
Microphone Inputs
|
32 |
|
Analog Line Inputs
|
16 |
|
Analog Line Outputs
|
24 |
|
Analog in/ out with plug-in card expandable
|
no |
|
Digital in-/ outputs expandable
|
no |
|
Word Clock
|
no |
|
Motorfader
|
yes |
|
Computer interface
|
USB, Ethernet |
|
MIDI-interface
|
no |
|
User Interface
|
Physical/remote |
|
Number of faders
|
33 |
|
DSP Input channels
|
64 |
|
DSP Output Channels
|
34 |
|
Busses
|
32 |
|
Mic Preamp
|
32 |
|
Mono-Line Input
|
34 |
|
Stereo-Line Input
|
2 |
|
Physical outputs
|
22 |
|
Digital stagebox connection
|
AVB |
|
Ethernet
|
Ethernet |
|
Hotspot
|
no |
|
Multitrack Record
|
yes |
|
Special Features
|
AVB |
|
Soundcard interface
|
USB-B |
|
integratated Player/Rec via USB/SD
|
Multitrack |
|
Recorder Format
|
WAV |
|
Scribble Strips
|
1 |
|
RTA
|
yes |
|
FX Processor
|
8 |
|
31 Band EQ
|
16 |
|
Delay Input
|
1 |
|
Delay Output
|
1 |
|
Matrix
|
0 |
|
DCA/VCA Gruppen
|
24 |
|
Midi Connector
|
no |
|
Sample rate
|
48 kHz |
|
Monitor Apps
|
1 |
|
Separate Personal Monitor system
|
Optional |
|
Expansion Card slots
|
0 |
|
Digital ADAT
|
no |
|
Digital SPDIF
|
no |
|
Digital AES3/ASESEB
|
no |
|
Digital MADI
|
no |
|
Digital Dante
|
no |
|
110V capable
|
1 |
|
Case
|
Optional |
|
19" Rackmount
|
no |
|
Height
|
165 mm |
|
Width
|
822 mm |
|
Depth
|
583 mm |
